Capacity
- Capacity (Cooling, Btu/hr)22000
- Capacity (Heating, Btu/hr)25200
- Capacity (Cooling, Min – Max, Btu/hr)4,700 ~ 25,900
- Capacity (Heating, Min – Max, Btu/hr)4,000 ~ 31,390
- Capacity (Cooling, kW)6.45
- Capacity (Heating, kW)7.39
- Capacity (Cooling, Min – Max, kW)1.38 ~ 7.59
- Capacity (Heating, Min – Max, kW)1.17 ~ 9.2
Energy Efficiency
- SEER(W/W, Energy Label)6.10
- SCOP(W/W, Energy Label)3.80
- EER (Cooling, W/W)2.83
- COP (Heating, W/W)2.85
- EER (Cooling, Btu/hW)9.65
- COP (Heating, Btu/hW)9.71
- Energy Efficiency Class for cooling (Grade)A++ / A
Noise Level
- Sound Power Level(Indoor, Cooling, dBA)62
- Sound Power Level(Outdoor, Cooling, dBA)68
- Noise Level (Indoor, High/Low, dBA)43 / 26
- Noise Level (Outdoor, High/Low, dBA)52
Electrical Data
- Power Source(Φ/V/Hz)1 / 220-240~/ 50
- Power Consumption(Cooling, W)2280
- Power Consumption(Heating, W)2595
- Operating Current(Cooling, A)10.2
- Operating Current(Heating, A)11.5
Physical specification
- Gross Dimension (Indoor, WxHxD, mm*mm*mm)1115*290*375
- Gross Dimension (Outdoor, WxHxD, mm*mm*mm)1023*724*413
- Net Dimension (Indoor, WxHxD, mm*mm*mm)1055*299*215
- Net Dimension (Outdoor, WxHxD, mm*mm*mm)880*638*310
- Gross Weight (Indoor, kg)13.2
- Gross Weight (Outdoor, kg)49.2
- Net Weight (Indoor, kg)11.5
- Net Weight (Outdoor, kg)43.8
- Loading Quantity (20/40/40Hft without Pipe)65 / 138 / 154
Technical Information
- Piping Length (Max, m)30
- Piping Height (Max, m)15
- SVC Valve (Liquid (ODxL))6.35
- SVC Valve (Gas (ODxL))15.88
- Moisture Removal (l/hr)2.5
- Air Circulation (Cooling, m3/min)17.2
- Refrigerant (Type)R410A
- Refrigerant (Charging, kg)1.45
- Low Ambient (Cooling, ℃)-10~46
- Low Ambient (Heating, ℃)-15~24
- Outdoor Unit (Compressor Type)BLDC
- Outdoor Unit (Anti-Corrosion Fin)Yes
Air Flow
- WindFree CoolingNo
- Air Direction Control (Up/Down)Auto
- Air Direction Control (Left/Right)Auto
- Air Flow Control Step (Cool/Fan)5/4
Air Purification
- PM 1.0 FilterNo
- Tri Care FilterNo
- Easy Filter Plus (Anti-Bacteria)Yes
- Auto Clean (Self Cleaning)Yes
Convenience
- SmartThingsYes
- AI Auto CoolingYes
- Motion Detect SensorNo
- Freeze WashNo
- Filter Cleaning IndicatiorYes
- Indoor Temp. DisplayYes
- Display On/OffYes
- Beep On/OffYes
- 24-Hour TimerYes
- Auto ChangeoverYes
- Auto RestartYes
Operating Mode
- Auto ModeYes
- Fast CoolYes
- Good SleepYes
- Eco ModeYes
- DehumidificationYes
- Fan ModeYes
- QuietYes
Smart
- WiFi EmbeddedYes
App Connectivity
- SmartThings App SupportYes
